Facebook Pixel and Conversions API for Magento

Rating:
95% of 100
$39.99
In stock
SKU
PMEFBP

Adds Meta Pixel (Facebook Pixel) and Meta Conversions API (Facebook Conversions API / Facebook Server-Side API) with standard events and Dynamic Ads code on appropriate pages. Supports Advanced Matching (if the customer is logged in) and has the ability to add custom parameters. Passes W3C validation. Easy to install and use.


Magento 2 Current Extension Version: 4.6.3

Compatibility

Open Source (CE): 2.0, 2.1, 2.2, 2.3, 2.4
Commerce using on prem (EE): 2.2, 2.3, 2.4
Commerce on Cloud (ECE): 2.2, 2.3, 2.4


Magento 1 Current Extension Version: 4.6.3

Compatibility

Open Source (CE): 1.5, 1.6, 1.6.1, 1.6.2.0, 1.7, 1.8, 1.8.1, 1.9, 1.9.1, 1.9.2, 1.9.3, 1.9.4
Commerce using on prem (EE): 1.10, 1.11, 1.11.1, 1.12, 1.13, 1.13.1, 1.14, 1.14.1, 1.14.2, 1.14.3, 1.14.4, 1.9.0.0, 1.9.1.0, 1.9.2.0

Links

Maximum 255 characters

All the latest requirements are already implemented.

Since version 4.4.0 you can send both the Meta Pixel (Facebook Pixel) event and Meta Conversions API (Facebook Conversions API) event simultaneously.

Add Meta Pixel (Facebook Pixel) and Meta Conversions API (Facebook Conversions API / Facebook Server-Side API) With Dynamic Ads code To Magento With Just A Few Clicks!

Compatible with both Magento v2 and Magento v1!

(Two separate versions of the extension. One for Magento v2 and one for Magento v1.)

Works great with Facebook Catalog Product Feed!

The Meta Pixel (Facebook Pixel) is a piece of JavaScript code for your website that enables you to measure, optimize and build audiences for your ad campaigns. Using the Meta Pixel (Facebook Pixel), you can leverage the actions people take on your website across devices to inform more effective Facebook advertising campaigns.

The Meta Conversions API (Facebook Conversions API / Facebook Server-Side API) (for web) allows advertisers to send web events from their servers directly to Meta (Facebook). Server-side events are linked to a pixel and are processed like browser pixel events. This means that server-side events are used in measurement, reporting, and optimization in the same way as browser pixel events.

Apptrian Meta Pixel (Facebook Pixel) and Conversions API extension for Magento adds Meta Pixel (Facebook Pixel) with Dynamic Ads code on CMS pages (including the home page), category pages, product pages, catalog search pages, catalog advanced search pages, customer registration page, checkout page (default Magento one but also any other without any coding, only by typing page handle (full action name) into our extension config.), and checkout success page. The extension supports Advanced Matching (if the customer is logged in) and has the ability to add custom parameters.

Optionally Meta Pixel (Facebook Pixel) block can be added to any other Magento page or any other extension page (blogs, form pages, etc.) via our extension config by typing page handle (full action name). The Meta Pixel (Facebook Pixel) allows you to place a single pixel on your entire website to report conversions, build audiences and get rich insights into how people use your website.

Conversion measurement lets you track actions people take after viewing your Facebook Ads across multiple devices, including mobile phones, tablets, and desktop computers. By creating a Meta Pixel (Facebook Pixel) and adding it to the pages of your website where conversions happen, like the checkout page, you will see who converts as a result of your Facebook Ads. The pixel will continue to monitor the actions people take after clicking on your ad. You can see which device they saw the ad on and which device they ultimately converted on.

Account & Pricing

To use this extension, a free Meta Business Suite (Facebook Business Suite) account is required.

NOTE: Meta (Facebook) advertising service is not free; additional charges apply to users running Meta (Facebook) Ad Campaigns.

Features

Meta Pixel (Facebook Pixel)

  • An easy way to enable or disable Meta Pixel (Facebook Pixel).
  • Advanced Matching (if the customer is logged in).
  • Works out of the box just type your Meta Pixel ID (Facebook Pixel ID) (or comma-separated IDs for multipixel setups) in our extension config.
  • Option to type page handles (full action names) where you want Meta Pixel (Facebook Pixel). Using this option Meta Pixel (Facebook Pixel) can be added to any other Magento page or any other extension page (blogs, form pages, etc.).
  • Option to enable or disable the Meta Pixel (Facebook Pixel) base code.
  • Option to enable or disable the Meta Pixel (Facebook Pixel) noscript tag.
  • Individual options to enable or disable AddToCart, AddToWishlist, CompleteRegistration, InitiateCheckout, PageView, Purchase, Search, and ViewContent events.
  • Option to fire PageView event with other events: CompleteRegistration, InitiateCheckout, Purchase, Search, and ViewContent.
  • Option to move parameters outside contents.
  • Options to detect selected SKUs for all product types including bundle, configurable, and grouped products. WARNING! *

* WARNING! Meta Pixel (Facebook Pixel) (client-side) detection of selected SKUs feature is heavily dependent on the theme you are using and its customization. It is impossible to predict all possible themes and customizations. Because of this detection will not work on every theme. This is why extension default configuration comes with this feature turned off. You can turn it on, try it out if it is working for you and if it does leave it on, otherwise turn it off. If you are a developer you will be pleased to know that everything is conveniently located in code.phtml file. To make it work, in some cases only the adjustment of a few jQuery selectors is needed in others complete rewrite of the detection code is needed. Because of this, we do not give any warranty for the detection feature, nor it is covered by our support service.

Unlike Meta Pixel (Facebook Pixel) client-side detection, the Facebook Server-Side detection is not dependent on the theme you are using and its customization. Therefore if you want to use detection, we recommend you to use server-side detection and events.

Meta Conversions API (Facebook Conversions API / Facebook Server-Side API)

  • An easy way to enable or disable Meta Conversions API (Facebook Conversions API / Facebook Server-Side API).
  • Advanced Matching (if the customer is logged in).
  • Option to type your Meta Access Token (Facebook Access Token) in our extension config.
  • Option to type your Meta API Version (Facebook API Version) in our extension config.
  • Option to type your Test Event Code in our extension config.
  • Option to log server-side fired events in the Magento log file.
  • Individual options to enable or disable AddToCart, AddToWishlist, CompleteRegistration, InitiateCheckout, PageView, Purchase, Search, and ViewContent events. * Notice
  • Option to fire PageView event with other events: CompleteRegistration, InitiateCheckout, Purchase, Search, and ViewContent.
  • Option to move parameters outside contents.
  • Options to detect selected SKUs for all product types including bundle, configurable, and grouped products.

* Notice Since version 4.4.0 you can send both the Meta Pixel (Facebook Pixel) event and Meta Conversions API (Facebook Conversions API) event simultaneously. The server-side events are not visible in the Meta Pixel Helper (Facebook Pixel Helper) extension for Chrome. You can see server-side events in your Meta Business Suite (Facebook Business Suite).

Category (Category Page)

  • Option to type page handles (full action names) where you want category-related code.
  • Option to type the event name you want to use for category tracking.
  • Options to add custom parameters to your category-related event with parameters to attributes mapping. Example: google_product_category=google_product_category|name=name. The format is simple param1=attribute1|param2=attribute2 Meta Pixel (Facebook Pixel) custom parameter and Magento category attribute are connected by = sign and pairs are separated by | sign.

Product (Product Page - AddToCart, AddToWishlist, ViewContent Events)

  • Option to type page handles (full action names) where you want product-related code.
  • Option to select SKU you want to use for bundle products. Options: Product SKU as (id), Children SKUs as (id)s, Children SKUs as (id)s and Product SKU as (item_group_id)
  • Option for content_type to use product_group instead of product for bundle products.
  • Option to select SKU you want to use for configurable products. Options: Product SKU as (id), Child SKU as (id), Child SKU as (id) and Product SKU as (item_group_id)
  • Option for content_type to use product_group instead of product for configurable products.
  • Option to select SKU you want to use for downloadable products. Options: Product SKU as (id), Product SKU as (id) and Parent SKU as (item_group_id)
  • Option to select SKU you want to use for grouped products. Options: Product SKU as (id), Children SKUs as (id)s, Children SKUs as (id)s and Product SKU as (item_group_id)
  • Option for content_type to use product_group instead of product for grouped products.
  • Option to select SKU you want to use for simple products. Options: Product SKU as (id), Product SKU as (id) and Parent SKU as (item_group_id)
  • Option to select SKU you want to use for virtual products. Options: Product SKU as (id), Product SKU as (id) and Parent SKU as (item_group_id)
  • Option to use content_ids instead of contents for the ViewContent event.
  • Option to type the Magento product attribute code you want to use for the global content_name parameter.
  • Option to type the Magento product attribute code you want to use for the global content_category parameter.
  • Options to add custom parameters to your product-related events with parameters to attributes mapping. Example: google_product_category=google_product_category|color=color. The format is simple param1=attribute1|param2=attribute2 Meta Pixel (Facebook Pixel) custom parameter and Magento product attribute are connected by = sign and pairs are separated by | sign.

Quote (Checkout Page - InitiateCheckout Event)

  • Option to type page handles (full action names) where you want quote-related code.
  • Option to select SKU you want to use for bundle products. Options: Product SKU as (id), Children SKUs as (id)s, Children SKUs as (id)s and Product SKU as (item_group_id)
  • Option to select SKU you want to use for configurable products. Options: Product SKU as (id), Child SKU as (id), Child SKU as (id) and Product SKU as (item_group_id)
  • Option to select SKU you want to use for downloadable products. Options: Product SKU as (id), Product SKU as (id) and Parent SKU as (item_group_id)
  • Option to select SKU you want to use for grouped products. Options: Children SKUs as (id)s, Children SKUs as (id)s and Product SKU as (item_group_id)
  • Option to select SKU you want to use for simple products. Options: Product SKU as (id), Product SKU as (id) and Parent SKU as (item_group_id)
  • Option to select SKU you want to use for virtual products. Options: Product SKU as (id), Product SKU as (id) and Parent SKU as (item_group_id)
  • Option to type parameter name if you want to use Magento quote ID.
  • Options to add custom parameters to your quote-related event with parameters to attributes mapping. Example: google_product_category=google_product_category|color=color. The format is simple param1=attribute1|param2=attribute2 Meta Pixel (Facebook Pixel) custom parameter and Magento product attribute are connected by = sign and pairs are separated by | sign.

Order (Checkout Success Page - Purchase Event)

  • Option to type page handles (full action names) where you want order-related code.
  • Option to select SKU you want to use for bundle products. Options: Product SKU as (id), Children SKUs as (id)s, Children SKUs as (id)s and Product SKU as (item_group_id)
  • Option to select SKU you want to use for configurable products. Options: Product SKU as (id), Child SKU as (id), Child SKU as (id) and Product SKU as (item_group_id)
  • Option to select SKU you want to use for downloadable products. Options: Product SKU as (id), Product SKU as (id) and Parent SKU as (item_group_id)
  • Option to select SKU you want to use for grouped products. Options: Children SKUs as (id)s, Children SKUs as (id)s and Product SKU as (item_group_id)
  • Option to select SKU you want to use for simple products. Options: Product SKU as (id), Product SKU as (id) and Parent SKU as (item_group_id)
  • Option to select SKU you want to use for virtual products. Options: Product SKU as (id), Product SKU as (id) and Parent SKU as (item_group_id)
  • Option to type parameter name if you want to use Magento order ID.
  • Option to type parameter name if you want to use Magento order increment ID.
  • Option to type parameter name if you want to use Magento quote ID.
  • Options to add custom parameters to your order-related event with parameters to attributes mapping. Example: google_product_category=google_product_category|color=color. The format is simple param1=attribute1|param2=attribute2 Meta Pixel (Facebook Pixel) custom parameter and Magento product attribute are connected by = sign and pairs are separated by | sign.

Search (Search Result Page - Search Event)

  • Option to type page handles (full action names) where you want search-related code.
  • Option to type the event name you want to use for search tracking.
  • Option to type the parameter name you want to use for search tracking.
  • Option to type request parameters you want to include for search tracking.

Data Processing Options

  • An easy way to enable or disable Data Processing Options.
  • Option to type Data Processing Options as a comma-separated list.
  • Option to type Data Processing Options Country
  • Option to type Data Processing Options State

Miscellaneous

  • Option to select Meta (Facebook) product identifier. Magento product SKU (Recommended) or Magento product ID.
  • Option for Advanced Matching data mapping. Example: external_id=external_id|em=em|ph=ph. The format is simple param1=key1|param2=key2 Meta (Facebook) parameter and data key are connected by = sign and pairs are separated by | sign. Available customer data keys are: em, ph, fn, ln, ge, db, ct, st, zp, country, external_id.
  • Options to connect default Magento "Cookie Restriction Mode" cookie or any third-party cookie consent extension or theme customization via following options: Enable Cookie Consent, Consent Cookie Name, Consent Cookie Key, Consent Cookie Value, and Consent Button.

Installation Instructions (For Magento v2)

There are several ways you can install any Magento extension. Our extension is no different. We will show you three ways to install the extension, but you must not mix them. Choose one and stick to it.

If you do not know how to install an extension or you wish a professional to do it for you, we offer an additional installation service for a small fee.

Installation via file uploading
(If you purchased the extension on our site)

If you purchased the extension on our site then unpack .zip file from /Magento2/InstallByUploadingFiles/ directory inside your Magento root.
- Run following commands on Magento root directory:
php bin/magento maintenance:enable
php bin/magento module:enable --clear-static-content Apptrian_FacebookPixel
php bin/magento setup:upgrade
php bin/magento cache:flush
php bin/magento setup:static-content:deploy
php bin/magento maintenance:disable
php bin/magento cache:flush

Installation via Composer
(If you purchased the extension on our site)

If you purchased the extension on our site then copy .zip file from /Magento2/InstallWithComposer/ directory inside your MAGENTO_ROOT/vendor/apptrian/packages/ directory (create directory if does not exist).
- Run following commands on Magento root directory:
php bin/magento maintenance:enable
composer config repositories.apptrianartifacts artifact $(pwd)/vendor/apptrian/packages
composer require apptrian/facebook-pixel
php bin/magento module:enable --clear-static-content Apptrian_FacebookPixel
php bin/magento setup:upgrade
php bin/magento cache:flush
php bin/magento setup:static-content:deploy
php bin/magento maintenance:disable
php bin/magento cache:flush

Installation via Composer
(If you purchased the extension on Magento Marketplace)

If you purchased the extension on Magento Marketplace then you must use Composer. Magento Marketplace does not allow extension downloads.
- Run following commands on Magento root directory:
php bin/magento maintenance:enable
composer require apptrian/facebook-pixel
php bin/magento module:enable --clear-static-content Apptrian_FacebookPixel
php bin/magento setup:upgrade
php bin/magento cache:flush
php bin/magento setup:static-content:deploy
php bin/magento maintenance:disable
php bin/magento cache:flush

Please make sure your Magento public and private keys are in your Magento root auth.json file. Usually, people install Magento with one Magento Marketplace account (public and private keys) and then purchase an extension with another Magento Marketplace account (different public and private keys). Check the Magento Marketplace account you used to purchase the extension and make sure its public and private keys are in the Magento root auth.json file. WARNING! if you already have keys there, be very careful because maybe some other extensions are purchased with another Magento Marketplace account.

Installation Instructions (For Magento v1)

- Log in to Magento Admin
- (Optional) Disable Magento Compiler if you are using it (System > Tools > Compilation)
- Go to System > Magento Connect > Magento Connect Manager
- If you purchased the extension on our site use the "Direct package file upload" section and "Upload package file". Browse to the .tgz file. Click the "Upload" button.
- If you purchased the extension on Magento Marketplace use the "Paste extension key to install" and paste Access Key you get from Magento Marketplace. Click the "Install" button. Click the "Proceed" button.
- Go back to Magento Admin
- Flush Magento Cache (System > Cache Management), then log out from Magento Admin and log back in
- (Optional) Enable Magento Compiler by clicking "Run Compilation Process" button (System > Tools > Compilation)

If you do not know how to install an extension or you wish a professional to do it for you, we offer additional Installation service for a small fee.

Configuration (For Magento v2)

Our extension works out of the box. The only thing you need to do is type your Pixel ID and Access Token in our extension configuration. To do this, log in to your Magento Admin and go to:

Stores > Configuration > Apptrian Extensions > Facebook Pixel and Conversions API > Facebook Pixel (Client-Side Settings) > Facebook Pixel ID

Stores > Configuration > Apptrian Extensions > Facebook Pixel and Conversions API > Facebook Conversions API (Server-Side Settings) > Facebook Access Token

See FAQ on how to get Access Token.

All options are self-explanatory and have comments and tooltips. Make sure you read them.

After changing options, make sure you refresh your Magento cache.

WARNING! You need to remove all other implementations of Meta Pixel (Facebook Pixel) and use only our extension.

  • Remove all other extensions that fire Meta Pixel (Facebook Pixel).
  • Remove all theme customizations that fire Meta Pixel (Facebook Pixel).
  • If you are using GTM (Google Tag Manager), make sure it is not firing Meta Pixel (Facebook Pixel) events.
  • If you have set "Event Triggers" in the "Event Setup Tool", you need to remove them all and then disable the "Track Events Automatically Without Code" option.

Configuration (For Magento v1)

Our extension works out of the box. The only thing you need to do is type your Pixel ID and Access Token in our extension configuration. To do this, log in to your Magento Admin and go to:

System > Configuration > Apptrian Extensions > Facebook Pixel and Conversions API > Facebook Pixel (Client-Side Settings) > Facebook Pixel ID

System > Configuration > Apptrian Extensions > Facebook Pixel and Conversions API > Facebook Conversions API (Server-Side Settings) > Facebook Access Token

See FAQ on how to get Access Token.

All options are self-explanatory and have comments and tooltips. Make sure you read them.

After changing options, make sure you refresh your Magento cache.

WARNING! You need to remove all other implementations of Meta Pixel (Facebook Pixel) and use only our extension.

  • Remove all other extensions that fire Meta Pixel (Facebook Pixel).
  • Remove all theme customizations that fire Meta Pixel (Facebook Pixel).
  • If you are using GTM (Google Tag Manager), make sure it is not firing Meta Pixel (Facebook Pixel) events.
  • If you have set "Event Triggers" in the "Event Setup Tool", you need to remove them all and then disable the "Track Events Automatically Without Code" option.

FAQ (For Magento v2)

Q: How do I get Facebook Access Token?
A: There are two ways of getting your Access Token:
- Via Events Manager (Recommended)
- Using Your Own App
To get Access Token via Events Manager (Recommended), go to Meta Business Suite (Facebook Business Suite) and Events Manager. Choose the pixel you want to implement. Select the Settings tab. Find the Conversions API section and click on Create Access Token under Set up manually, and follow the instructions pop up. Once you have your token (save it to your computer because you will not be able to see it again). The Events Manager gives you access to a new tab called Implementation. Navigate to the Implementation tab and follow the instructions displayed on the screen. This way, Facebook automatically creates a Conversions API App and Conversions API System User for you. There is no need to go through the app review or request any permissions.

Q: Meta Conversions API (Facebook Conversions API / Facebook Server-Side API) does not work?
A: Meta (Facebook) deprecated v6.0 of the Server-Side API. Go to our extension config and for the Meta API Version (Facebook API Version) option type v12.0 or newer, then refresh your Magento cache (System > Cache Management) and you are done.

Q: In Meta Event Manager (Facebook Event Manager), there are errors "(X) Event Missing Deduplication Parameter"?
A: This error is caused by using other Meta Pixel (Facebook Pixel) solutions in parallel with ours. You need to remove all other implementations of Meta Pixel (Facebook Pixel) and use only our extension. That means:
- Remove all other extensions that fire Meta Pixel (Facebook Pixel).
- Remove all theme customizations that fire Meta Pixel (Facebook Pixel).
- If you are using GTM (Google Tag Manager), make sure it is not firing Meta Pixel (Facebook Pixel) events.
- If you have set "Event Triggers" in the "Event Setup Tool", you need to remove them all and then disable the "Track Events Automatically Without Code" option.

Q: Is it possible to add the Meta Pixel (Facebook Pixel) to other Magento pages or extension pages?
A: Yes it is. In our extension config just use the option "Add Meta Pixel (Facebook Pixel) To" and type your page handle (full action name). For example, if you want to add Meta Pixel (Facebook Pixel) to a blog page and that blog page handle is "blog_post_view", you would type this into "Add Meta Pixel (Facebook Pixel) To" at the end. Page handle depends on a particular extension this is just an example. Do not forget to Refresh your Magento Cache.

Q: When I check my product pages with the "Meta Pixel Helper (Facebook Pixel Helper)" extension for Chrome the AddToCart and AddToWishlist events have orange triangles with warnings?
A: The "Meta Pixel Helper (Facebook Pixel Helper)" extension for Chrome does not understand JavaScript/jQuery that is why on page load you have orange triangles for AddToCart and AddToWishlist events. If you read the warnings of the "Meta Pixel Helper (Facebook Pixel Helper)" there is an explanation: "We detected event code but the pixel has not activated for this event, so no information was sent to Meta (Facebook). This could be due to an error in the code, but could also occur if the pixel fires on a dynamic event such as a button click." AddToCart and AddToWishlist are dynamic events triggered by a button click. After you click a button they will become green. This has nothing to do with our extension nor Meta Pixel (Facebook Pixel), it is the behavior of the "Meta Pixel Helper (Facebook Pixel Helper)" extension for Chrome. In short, this is normal.

FAQ (For Magento v1)

Q: How do I get Meta Access Token (Facebook Access Token)?
A: There are two ways of getting your Access Token:
- Via Events Manager (Recommended)
- Using Your Own App
To get Access Token via Events Manager (Recommended), go to Meta Business Suite (Facebook Business Suite) and Events Manager. Choose the pixel you want to implement. Select the Settings tab. Find the Conversions API section and click on Create Access Token under Set up manually, and follow the instructions pop up. Once you have your token (save it to your computer because you will not be able to see it again). The Events Manager gives you access to a new tab called Implementation. Navigate to the Implementation tab and follow the instructions displayed on the screen. This way, Facebook automatically creates a Conversions API App and Conversions API System User for you. There is no need to go through the app review or request any permissions.

Q: Meta Conversions API (Facebook Conversions API / Facebook Server-Side API) does not work?
A: Meta (Facebook) deprecated v6.0 of the Server-Side API. Go to our extension config and for the Meta API Version (Facebook API Version) option type v12.0 or newer, then refresh your Magento cache (System > Cache Management) and you are done.

Q: In Meta Event Manager (Facebook Event Manager), there are errors "(X) Event Missing Deduplication Parameter"?
A: This error is caused by using other Meta Pixel (Facebook Pixel) solutions in parallel with ours. You need to remove all other implementations of Meta Pixel (Facebook Pixel) and use only our extension. That means:
- Remove all other extensions that fire Meta Pixel (Facebook Pixel).
- Remove all theme customizations that fire Meta Pixel (Facebook Pixel).
- If you are using GTM (Google Tag Manager), make sure it is not firing Meta Pixel (Facebook Pixel) events.
- If you have set "Event Triggers" in the "Event Setup Tool", you need to remove them all and then disable the "Track Events Automatically Without Code" option.

Q: Is it possible to add the Meta Pixel (Facebook Pixel) to other Magento pages or extension pages?
A: Yes it is. In our extension config just use the option "Add Meta Pixel (Facebook Pixel) To" and type your page handle (full action name). For example, if you want to add Meta Pixel (Facebook Pixel) to a blog page and that blog page handle is "blog_post_view", you would type this into "Add Meta Pixel (Facebook Pixel) To" at the end. Page handle depends on a particular extension this is just an example. Do not forget to Refresh your Magento Cache.

Q: When I check my product pages with the "Meta Pixel Helper (Facebook Pixel Helper)" extension for Chrome the AddToCart and AddToWishlist events have orange triangles with warnings?
A: The "Meta Pixel Helper (Facebook Pixel Helper)" extension for Chrome does not understand JavaScript/jQuery that is why on page load you have orange triangles for AddToCart and AddToWishlist events. If you read the warnings of the "Meta Pixel Helper (Facebook Pixel Helper)" there is an explanation: "We detected event code but the pixel has not activated for this event, so no information was sent to Meta (Facebook). This could be due to an error in the code, but could also occur if the pixel fires on a dynamic event such as a button click." AddToCart and AddToWishlist are dynamic events triggered by a button click. After you click a button they will become green. This has nothing to do with our extension nor Meta Pixel (Facebook Pixel), it is the behavior of the "Meta Pixel Helper (Facebook Pixel Helper)" extension for Chrome. In short, this is normal.

Write Your Own Review
Only registered users can write reviews. Please Sign in or create an account
Copyright © 2021 Apptrian.com. All rights reserved.
